6V 9Ah Sealed Lead Acid Battery with F2 Terminals

Features of the TLV690F2 - 6V 9Ah Sealed Lead Acid Battery with F2 Terminals
• Absorbent Glass Mat (AGM) technology for efficient gas recombination of up to 99% and freedom from electrolyte maintenance or water adding
• Not restricted for air transport-complies with IATA/ICAO Special Provision A67
• UL-recognized component
• Can be mounted in any orientation
• Computer designed lead, calcium tin alloy grid for high power density
• Long service life in float or cyclic applications
• Maintenance-free operation
• Low self discharge
Applications
• UPS Standby Power Applications
• Data Centers
• Emergency 911 Centers
• Hospitals & Medical Applications
• Military Power Equipment
• Emergency Lighting
• Fire Detection and Alarm Devices
Product Specifications
Dimensions
Terminal Type: F2
Length (mm/inch): 151/5.94
Width (mm/inch): 34/1.33
Height (mm/inch): 94/3.70
Total Height (mm/inch): 100/3.93
Approx. Weight (kg/lbs): 1.43/3.15
Performance Characteristics
Nominal Capacity 77ºF (25ºC)
20HR (5.25V): 9Ah
10HR (5.25V): 8.4Ah
5HR (5.25V): 7.7Ah
1HR (4.80V): 6.3Ah
Internal Resistance
Fully Charged battery 77ºF(25ºC): Approx. 12mΩ
Self-Discharge (25°C)
3% of capacity declined per month at 20ºC (average)
Operating Temperature Range
Discharge: -20～60°C
Charge: -10～60°C
Storage: -20～60°C
Charge Methods: Constant Voltage Charge 77ºF(25ºC)
Cycle Use: 2.30-2.35VPC
Maximum charging current: 40% of Rated Capacity
Temperature Compensation: -30mV/ºC
Standby Use: 2.23-2.27VPCTemperature Compensation: -15mV/ºC
Constant Current Discharge Characteristics
Constant Power Discharge Characteristics
(Note) The above characteristics data are average values obtained within three charge/discharge cycles not the mimimum values.
Battery Construction
